Many homeowners face the task of replacing garage door springs at some point, which can seem overwhelming. The tension in these springs and the risk of injury may make you hesitant to take on the project yourself. However, with a clear understanding of the tools and steps involved, replacing your garage door springs can be safe and manageable.
This blog covers everything you need to know about garage door springs, from identifying whether you have extension or torsion springs to safely replacing them. You’ll also learn about common signs that your springs need replacement and essential safety precautions to remember throughout the process.
Whether you’re handling the repair independently or deciding if a professional is necessary, this guide breaks down the details so you can confidently proceed. Keep reading to ensure a safe, successful spring replacement for a well-functioning garage door.
Types of Garage Door Springs
Before starting any replacement process, it is essential to understand the type of spring your garage door uses. Garage doors typically use extension or torsion springs; each type functions differently. Knowing the differences will help you approach the repair safely and effectively.
Extension Springs
Extension springs are parallel to the horizontal tracks on both sides of the garage door. These springs extend as the door closes and contract when it opens, essentially pulling the door upward. They are often found in lighter, smaller garage doors like those used for single-car garages. One advantage is that they are easier to install and replace, making them ideal for DIY replacements. However, they are less durable than torsion springs and require frequent adjustments.
Torsion Springs
Torsion springs, in contrast, are installed horizontally above the garage door on a metal shaft. These springs store energy through a twisting motion, applying torque to lift the door smoothly. Torsion springs are more robust and last longer, making them ideal for heavier or frequently used garage doors. Due to their complexity and significant tension, replacing torsion springs is more complicated and dangerous than extension springs.
Signs Your Garage Door Springs Need Replacement
It’s essential to recognize the early signs that your garage door springs need replacement to avoid sudden failure, which could lead to accidents or more costly repairs.
Visual Indicators
Routine inspections can help you catch problems early. Signs that your springs may need to be replaced include:
- Rust: Corrosion weakens the spring over time, causing it to snap suddenly.
- Gaps in the coil: The spring is likely overstretched and ineffective if you see gaps between the coils.
- Broken springs: If a spring has broken into two or more pieces, it needs immediate replacement. A loud bang usually accompanies a break.
Garage Performance Issues
Garage door springs do most of the heavy lifting. If you notice performance issues such as:
- The door feels heavy or challenging to lift manually.
- The door won’t stay in the fully open position.
- The opener strains to lift the door or operates slower than usual. These are all signs that your springs may be worn out or broken and need replacing. Other indicators include unusual noise during operation, such as grinding or squealing sounds, which could mean the springs are under strain.
Safety Considerations for DIY Garage Spring Replacement
Garage door springs, especially torsion springs, are under extreme tension, making them dangerous to handle. Always take appropriate safety measures when attempting DIY replacement.
Protective Gear
Before starting any repair, ensure you have the right protective gear. This includes:
- Thick gloves: To protect your hands from sharp edges and sudden snaps.
- Safety goggles: To shield your eyes from any debris or flying parts.
- Closed-toe shoes: Steel-toe boots protect your feet if tools or parts fall.
- Helper: Someone assisting you can make the process smoother and safer by stabilizing the door or passing tools.
In addition, make sure to work on the door when it’s fully closed and unplug the automatic opener to prevent it from being accidentally engaged.
How to Replace Extension Springs on a Garage Door
Replacing extension springs is less complex than torsion springs, making it a manageable DIY project with the right tools and steps.
Tools and Equipment Needed
Before starting, gather the necessary tools:
- Adjustable wrench
- Safety glasses and gloves
- Locking pliers or clamps
- Tape measure
- Replacement springs (properly sized)
- Step ladder
- Socket wrench set
Measure and Purchase New Springs
To buy the correct replacement springs, you need to measure the old ones:
- Length: Measure the entire length of the spring when it’s uncompressed.
- Wire thickness: Measure the thickness of the spring wire using a caliper or a ruler.
- Color coding: Most extension springs have color-coded ends indicating their strength. Match this color when purchasing your replacements.
Installing New Extension Springs
- Disconnect the power: Unplug the garage door opener to prevent accidental operation.
- Release the tension: Fully open the garage door and secure it using clamps or locking pliers. This ensures the door won’t move while you work on the springs.
- Remove the old springs: Detach the spring from the mounting brackets and the track. Pay attention to how the spring is attached to ensure correct reinstallation.
- Install the new springs: Attach the new spring to the same brackets and track where the old one was removed. Ensure the hooks and loops are securely fastened, and the tension is even on both sides.
- Test the door: Carefully remove the clamps and lower the door to check its operation. Reconnect and test the opener several times to ensure the door operates smoothly.
How to Replace Torsion Springs on a Garage Door
Due to the high tension involved, replacing torsion springs is more technical and dangerous. It requires precision, strength, and specialized tools.
Tools and Equipment Needed
To replace torsion springs, you’ll need:
- Winding bars (never use screwdrivers or improvised tools)
- Adjustable wrench
- Vice grips or C-clamps
- Socket wrench set
- Tape measure
- Replacement torsion springs (properly measured)
Measure and Buy New Springs
To find the right replacement spring, measure:
- Wire diameter: Use a caliper to measure the thickness of the wire.
- Spring length: Measure the overall length of the spring when it’s uncompressed.
- Inside diameter: This is the diameter of the spring’s inner hole.
- Wind direction: Check if your spring is left or right-wind by its placement.
Installing New Torsion Springs
- Release the tension: Use the winding bars to slowly and safely unwind the tension in the old springs. This is a critical safety step, as improper handling can cause the spring to snap.
- Remove the old springs: After the tension is released, loosen the set screws on the torsion tube and slide off the old spring.
- Install the new torsion springs: Slide the new spring onto the tube, ensuring it is correctly oriented (right-wind or left-wind). Tighten the set screws.
- Wind the new springs: Using the winding bars, apply the correct number of turns based on the manufacturer’s instructions. This typically involves applying about 30-35 quarter turns.
- Test the door: Once the springs are wound, manually lift the door to check for balance. When left halfway open, it should remain in place.
Troubleshooting Common Issues After Garage Spring Replacement
Even after successful installation, you may encounter minor issues. Here’s how to address them.
Garage Door Balance Problems
If the garage door doesn’t stay open or closes too quickly after the spring replacement, the springs may not be balanced correctly. Test the door manually by lifting it halfway. If it falls or rises, you need to adjust the spring tension.
Spring Tension Adjustments
For extension springs, adjust the tension by repositioning the hook on the end of the spring. For torsion springs, carefully add or remove a quarter turn using the winding bars until the door moves smoothly and is balanced.
When To Call a Professional for Your Garage
While DIY replacements can save you money, there are instances where a professional’s expertise is necessary.
Complex Installation Scenarios
If your garage door has a custom spring setup or multiple doors, or the spring size and configuration seem complicated, calling a professional ensures the job is done safely and correctly.
Safety Concerns
If you are unsure about your ability to handle high-tension springs or the tools are unfamiliar, it’s best to leave the replacement to a professional to avoid injury or property damage.
Maintenance Tips To Extend Garage Spring Life
Regular maintenance can help extend the life of your garage springs, saving you from frequent replacements.
Regular Garage Inspections
Inspect the springs every few months for signs of wear, rust, or gaps in the coils. Catching these issues early can prevent sudden spring failure and prolong the springs’ life.
Lubrication and Cleaning Garage Springs
Use a silicone-based lubricant on the springs to keep them operating smoothly and reduce friction. Clean off any dirt or debris that could affect the spring’s movement. Avoid using grease, as it attracts dust and can clog the system.
Garage Door Spring Replacement Cost
The cost of replacing garage door springs varies depending on whether you choose a DIY approach or hire a professional.
DIY vs. Professional Costs
For DIY replacement, expect to spend between $50 and $150 on springs alone, while professional replacement typically ranges from $200 to $400, including labor. The cost can go higher if additional repairs are needed.
Factors Affecting Replacement Expenses
\Factors such as the type of spring, the size of your new garage door, and your location can influence the overall cost. Custom or heavy-duty springs will also cost more to replace.
Frequently Asked Questions (FAQs)
Can you lift a garage door with a broken spring?
Lifting a garage door with a broken spring is challenging and potentially dangerous. The spring supports the door’s weight, so it becomes extremely heavy without it. It’s best to avoid lifting it manually, as it can cause injury or damage. Instead, contact a professional to replace the spring safely.
How do I know what garage door spring I need?
To determine the correct garage door spring, measure the coil’s length, wire diameter, and inner diameter. Count the number of coils to ensure the right tension. If unsure, consult the garage door’s manufacturer or a professional technician who can accurately identify the needed spring.
How do I know if my garage door spring is weak?
A weak garage door spring may cause the door to open slowly or unevenly. You might also notice the door needing help to stay in an open position or closing too quickly. If you observe these symptoms, the spring likely needs adjustment or replacement to ensure safe operation.
Are all garage springs the same size?
No, garage springs are not all the same size. They vary based on the garage door’s weight, height, and design. Torsion springs differ in length, wire diameter, and coil size, while extension springs vary in length and tension capacity. Matching the spring size to your specific garage door is crucial for safe and efficient operation.
Can a garage door work without springs?
A garage door cannot operate appropriately without springs. The springs counterbalance the door’s weight, making it possible to lift it easily. Without springs, the door becomes too heavy to lift manually or by the opener, and attempting to do so can damage the door or injure the user.
Wrapping Up
Wrapping up, and replacing garage door springs is a crucial maintenance task that demands attention to detail, proper tools, and safety precautions. Whether you choose to take on the project yourself or enlist the help of a professional, understanding the differences between extension and torsion springs is key.
Following the correct installation steps, using the right equipment, and regularly inspecting and maintaining your springs can extend their lifespan and prevent costly garage door repairs. Remember, while DIY replacements can save money, safety should always come first, and professional assistance is advised if you’re unsure of the process. Proper care ensures smooth, long-lasting garage door performance.
